Specifications

Stand

Color
Gold		 Material
Aluminum / Oak		 TV Height Adjustment
Electric Height Adustment
(Remote Control)
TV Swivel
L or R 30°		 Cable Management
YES

Display

Size
75 Inch		 Backlight
QLED		 Maximum Resolution
4K (3840x2160)
Contrast Ratio (Typ)
1200:1		 Response Time (Typ)
8ms		 Display Scale
16:09
Viewing Angle (CR>10)
Typ(H:178°,V:178°)		 Display Colors
1.07B		 Color Gamut (NTSC)
≥NTSC 90%
Uniformity of Luminance
≥75%		 LCM Center Luminance of White
Min.:300cd/m2;Typ.350cd/m2		 Refresh Rate
60Hz
HDR
HDR10

Audio

Sound Output(RMS)
16W		 Speaker Type
2CH		 Dolby Digital
YES

Chip

CPU Frame
4-core CPU
with 2 performance cores
and 2 efficiency cores		 RAM
1.5G		 ROM
8G

Smart

Smart TV
YES		 TV Smart System
WebOS		 TV APP Store
YES
TV Web Boswne
YES		 Sleep Time Setting
YES		 OTA
YES

Connectivity

HDMI
3		 HDMI-ARC
HDMI-2		 HDMI-CEC
YES
USB
2		 VGA
0		 AV In
1
RJ-45
1		 Earphone
1		 Bluetooth (Version)
5
WIFI (Type)
2TR2

Dimension

Size(With Stand)WxDxH
1669x576x1500-1700mm
(TV Height Adjustment)		 Stand Size (Without TV)WxDxH
1054x576x1339mm		 TV Size(Without Stand)
1669x103x958

Power Management

Power Input
100-240VAc		 Fire Rating
UL94-HB75		 Standby Power
≤0.5W
Rated Power
2*56*600mA(LB)@320W
4*36*550mA(LB)@365W		 Working Condition
Temperature：5℃～40℃
humidity：20%～80%		 Storage Condition
Temperature：-20℃～55℃
humidity：20%～80%

Accessory

Remote Control
1pcs		 User Guide
1pcs		 Installing Guide
1pcs
HDMI Cable
1pcs		 Power Cable
1pcs
